ShapeFuns.h File Reference

#include <vector>
#include <algorithm>
#include "Shared/ProjectInterface.h"
#include "ShapeTypes.h"
#include "ShapeRoot.h"

Include dependency graph for ShapeFuns.h:

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Classes
class	UnaryShapeRootPred
	Unary predicates over ShapeRoot objects.
class	BinaryShapeRootPred
	Binary predicates over ShapeRoot objects. More...
class	UnaryShapePred< T >
	Unary predicates over Shape<T> objects. More...
class	BinaryShapePred< T >
	Binary predicates over Shape<T> objects. More...
class	shortcircuit_and< PredType1, PredType2 >
	Classes for implementing shortcircuit And and Or predicates. Don't call directly; use AndPred and OrPred; use not1 for negation. More...
class	shortcircuit_or< PredType1, PredType2 >
class	IsType
class	IsColor
class	IsName
class	IsNamePrefix
class	IsLastMatch
class	IsLeftOf
class	IsLeftOfThis
class	IsRightOf
class	IsRightOfThis
class	IsAbove
class	IsAboveThis
class	IsBelow
class	IsBelowThis
Namespaces
namespace	DualCoding
	Dual coding vision representations (Sketches and Shapes).
Defines
#define	NEW_SHAPE(_name, _type, _value)
	Create a new shape and make it visible in the SketchGUI.
#define	NEW_SHAPE_N(_name, _type, _value)
	Create a new shape but hide it from the SketchGUI.
#define	GET_SHAPE(_name, _type, _shapevec)   DualCoding::Shape<_type> _name(find_shape<_type>(_shapevec,#_name));
	Retrieve a shape based on its name.
#define	GET_RENAMED(_new_name, _old_name, _type, _shapevec)   DualCoding::Shape<_type> _new_name(find_shape<_type>(_shapevec,#_old_name));
	Retrieve a shape based on its name, but bind to a new name.
#define	NEW_SHAPEVEC(_name, _type, _value)   std::vector<DualCoding::Shape<_type> > _name((_value));
	Create a new vector of shapes of the specified type.
#define	NEW_SHAPEROOTVEC(_name, _value)   std::vector<DualCoding::ShapeRoot> _name((_value));
	Create a new vector of shapes of mixed type.
#define	SHAPEVEC_ITERATE(_shapesvec, _type, _var)
	Iterate over the shapes in a vector; _var is the iterator.
#define	SHAPENEXT_ITERATE(_shapesvec, _type, _var1, _var2)
	Nested iteration over the shapes in a vector; _var2 begins one past _var1.
#define	SHAPEROOTVEC_ITERATE(_shapesvec, _var)
	Iterate over a vector for shapes of mixed type.
#define	END_ITERATE   }
#define	DO_SHAPEVEC(_shapesvec, _type, _var, _body)
	Obsolete: Iterate over the shapes in a vector; _var is the iterator.
#define	DO_SHAPENEXT(_shapesvec, _type, _var1, _var2, _body)
	Obsolete: nested iteration over the shapes in a vector; _var2 begins one past _var1.
#define	DO_SHAPEROOTVEC(_shapesvec, _var, _body)
	Obsolete: Iterate over a vector for shapes of mixed type.
#define	DIRECTION_PAIR(dir, oppdir)
Functions
template<typename PredType >
ShapeRoot	find_if (const std::vector< ShapeRoot > &vec, PredType pred)
	Find a ShapeRoot satisfying pred.
template<class T , typename PredType >
Shape< T >	find_if (const std::vector< ShapeRoot > &vec, PredType pred)
	Find a Shape<T> in a vector of ShapeRoot satisfying pred.
template<class T , typename PredType >
Shape< T >	find_if (const std::vector< Shape< T > > &vec, PredType pred)
	Find a Shape<T> satisfying pred.
template<class T >
Shape< T >	find_if (const std::vector< ShapeRoot > &vec)
	Find a Shape<T> in a vector of ShapeRoot.
ShapeRoot	find_shape (const std::vector< ShapeRoot > &vec, const std::string &name)
	Return the first ShapeRoot with the specified name, else return an invalid ShapeRoot.
template<class T >
std::vector< Shape< T > >	select_type (std::vector< ShapeRoot > &vec)
	Select the Shape<T> elements from a vector of ShapeRoots.
template<class T , typename PredType >
std::vector< Shape< T > >	subset (const std::vector< Shape< T > > &vec, PredType pred)
	Find all elements in a vector of Shape<T> satisfying pred.
template<typename PredType >
std::vector< ShapeRoot >	subset (const std::vector< ShapeRoot > &vec, PredType pred)
	Find all elements in a vector of ShapeRoot satisfying pred.
template<class T , typename PredType >
std::vector< T >	subset (const std::vector< ShapeRoot > &vec, PredType pred)
	Find all elements of type T in a vector of ShapeRoot satisfying pred.
template<class T , typename ComparisonType >
Shape< T >	max_element (const std::vector< Shape< T > > &vec, ComparisonType comp)
template<typename ComparisonType >
ShapeRoot	max_element (const std::vector< ShapeRoot > &vec, ComparisonType comp)
template<class T , typename ComparisonType >
Shape< T >	min_element (const std::vector< Shape< T > > &vec, ComparisonType comp)
template<typename ComparisonType >
ShapeRoot	min_element (const std::vector< ShapeRoot > &vec, ComparisonType comp)
template<class T , typename PredType >
std::vector< Shape< T > >	stable_sort (const std::vector< Shape< T > > &vec, const PredType &pred)
template<typename PredType >
std::vector< ShapeRoot >	stable_sort (const std::vector< ShapeRoot > &vec, const PredType &pred)
template<typename PredType1 , typename PredType2 >
shortcircuit_and< PredType1, PredType2 >	AndPred (PredType1 p1, PredType2 p2)
	Conjunction of two predicates; p2 is called only if p1 returns true.
template<typename PredType1 , typename PredType2 >
shortcircuit_or< PredType1, PredType2 >	OrPred (PredType1 p1, PredType2 p2)
	Disjunction of two predicates; p2 is called only if p1 returns false.

---

Define Documentation

#define DIRECTION_PAIR	(	dir,
		oppdir		)

Definition at line 366 of file ShapeFuns.h.

#define DO_SHAPENEXT	(	_shapesvec,
		_type,
		_var1,
		_var2,
		_body		)

Value:

for ( std::vector<DualCoding::Shape<_type> >::iterator _var2##_it = ++std::vector<DualCoding::Shape<_type> >::iterator(_var1##_it); \
        _var2##_it != _shapesvec.end(); _var2##_it++ ) { \
    DualCoding::Shape<_type> &_var2 = *_var2##_it; \
    _body }

Obsolete: nested iteration over the shapes in a vector; _var2 begins one past _var1.

Definition at line 75 of file ShapeFuns.h.

Referenced by BrickData::findBricks().

#define DO_SHAPEROOTVEC	(	_shapesvec,
		_var,
		_body		)

Value:

for ( std::vector<DualCoding::ShapeRoot>::iterator _var##_it = _shapesvec.begin(); \
        _var##_it != _shapesvec.end(); _var##_it++ ) { \
    DualCoding::ShapeRoot &_var = *_var##_it; \
    _body }

Obsolete: Iterate over a vector for shapes of mixed type.

Definition at line 82 of file ShapeFuns.h.

Referenced by DualCoding::select_type().

#define DO_SHAPEVEC	(	_shapesvec,
		_type,
		_var,
		_body		)

Value:

for ( std::vector<DualCoding::Shape<_type> >::iterator _var##_it = _shapesvec.begin(); \
        _var##_it != _shapesvec.end(); _var##_it++ ) { \
    DualCoding::Shape<_type> &_var = *_var##_it; \
    _body } \

Obsolete: Iterate over the shapes in a vector; _var is the iterator.

Definition at line 68 of file ShapeFuns.h.

Referenced by BrickData::findBricks().

#define END_ITERATE   }

Definition at line 65 of file ShapeFuns.h.

Referenced by BiColorMarkerData::extractMarkers(), and AgentData::findCirclesManual().

#define GET_RENAMED	(	_new_name,
		_old_name,
		_type,
		_shapevec		)	DualCoding::Shape<_type> _new_name(find_shape<_type>(_shapevec,#_old_name));

Retrieve a shape based on its name, but bind to a new name.

Definition at line 36 of file ShapeFuns.h.

#define GET_SHAPE	(	_name,
		_type,
		_shapevec		)	DualCoding::Shape<_type> _name(find_shape<_type>(_shapevec,#_name));

Retrieve a shape based on its name.

Definition at line 32 of file ShapeFuns.h.

#define NEW_SHAPE	(	_name,
		_type,
		_value		)

Value:

DualCoding::Shape<_type> _name((_value)); \
  if ( _name.isValid() ) _name->V(#_name);

Create a new shape and make it visible in the SketchGUI.

Definition at line 22 of file ShapeFuns.h.

Referenced by BrickData::addBrickWithTwoSides(), SiftData::displayMatchedFeatures(), AprilTagData::extractAprilTags(), BrickData::extractBrick(), TargetData::extractLineTarget(), PyramidData::extractPyramid(), PyramidData::findBoundingTriangle(), BrickData::findBricks(), BlobData::findCorners(), BlobData::findCornersDerivative(), BlobData::findCornersDiagonal(), BlobData::findCornersShapeFit(), BrickData::findOrthogonalBoundingBox(), TargetData::mergeWith(), and TargetData::updateParams().

#define NEW_SHAPE_N	(	_name,
		_type,
		_value		)

Value:

NEW_SHAPE(_name, _type, _value); \
  if ( _name.isValid() ) _name->N(#_name);

Create a new shape but hide it from the SketchGUI.

Definition at line 27 of file ShapeFuns.h.

Referenced by BrickData::findBricks(), AgentData::findCirclesManual(), and BrickData::findOrthogonalBoundingBox().

#define NEW_SHAPEROOTVEC	(	_name,
		_value		)	std::vector<DualCoding::ShapeRoot> _name((_value));

Create a new vector of shapes of mixed type.

Definition at line 44 of file ShapeFuns.h.

#define NEW_SHAPEVEC	(	_name,
		_type,
		_value		)	std::vector<DualCoding::Shape<_type> > _name((_value));

Create a new vector of shapes of the specified type.

Definition at line 40 of file ShapeFuns.h.

Referenced by TargetData::extractLineTarget(), BiColorMarkerData::extractMarkers(), and AgentData::findCirclesManual().

#define SHAPENEXT_ITERATE	(	_shapesvec,
		_type,
		_var1,
		_var2		)

Value:

for ( std::vector<DualCoding::Shape<_type> >::iterator _var2##_it = ++std::vector<DualCoding::Shape<_type> >::iterator(_var1##_it); \
        _var2##_it != _shapesvec.end(); _var2##_it++ ) { \
    DualCoding::Shape<_type> &_var2 = *_var2##_it;

Nested iteration over the shapes in a vector; _var2 begins one past _var1.

Definition at line 54 of file ShapeFuns.h.

Referenced by BiColorMarkerData::extractMarkers().

#define SHAPEROOTVEC_ITERATE	(	_shapesvec,
		_var		)

Value:

for ( std::vector<DualCoding::ShapeRoot>::iterator _var##_it = _shapesvec.begin(); \
        _var##_it != _shapesvec.end(); _var##_it++ ) { \
    DualCoding::ShapeRoot &_var = *_var##_it;

Iterate over a vector for shapes of mixed type.

Definition at line 60 of file ShapeFuns.h.

#define SHAPEVEC_ITERATE	(	_shapesvec,
		_type,
		_var		)

Value:

for ( std::vector<DualCoding::Shape<_type> >::iterator _var##_it = _shapesvec.begin(); \
        _var##_it != _shapesvec.end(); _var##_it++ ) { \
    DualCoding::Shape<_type> &_var = *_var##_it;

Iterate over the shapes in a vector; _var is the iterator.

Definition at line 48 of file ShapeFuns.h.

Referenced by BiColorMarkerData::extractMarkers(), and AgentData::findCirclesManual().
